Details
Dual mechanism designed for easy pedal entry, secure cleat holding and positive, consistent release
Dual sided
Fully CNC Machined pedal bodies
Stainless steel clips and cleats
Pedals supplied with two cleats options
Large shoe/pedal contact area for maximum power transfer and stability
Replaceable pins for increased grip on Union GC (14 pins)
Foot plate option on Pedal for maximum shoe/pedal contact
Pedals run on three cartridge bearings and a norglide bush for smooth long term durability
Fully serviceable and re-buildable
Axle is high strength Cr-Mo, heat treated and plated
Titanium axle upgrades available
Q-Factor – 55mm
Pedals supplied with two cleats options; 4°or 5° of free float and 12° or 13° release angle respectively. Both cleats also allow 2mm of lateral (side to side) float.
Large platform with 4 pins per side for increased contact with the shoe sole and greater stability for more aggressive riding.
Weight from: 437g
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Black | 5056454903836 | 210000061685 |
Blue | 5056454903812 | 210000061681 |
Orange | 5056454903829 | 210000061683 |
Silver | 5056454903867 | 210000061691 |
